Sharpy Plus

CD3000

Sharpy Plus is the first true 100% HYBRID unit, able to be a perfect beam light and a perfect spotlight.  It is suitable for every occasion, with an extraordinary luminous efficiency which ensures substantial savings through lower power consumption.

The Sharpy Plus fits a totally new, top-ranking-performance Osram Sirius HRI 330W X8 lamp and weighs only 23 kg (50.7 lbs). All its functions are extremely quick. Its body is slightly larger than the Sharpy’s, to house a high quality optical unit with a zoom that ranges from 3° to 36°. Its minimum beam angle of 3° makes it possible to generate the narrow parallel light beams essential for beam light mode. Its wide zoom range also allows large beam angles, which makes the Sharpy Plus a perfect spotlight for all purposes.

The Sharpy Plus has two independent operating modes. In BEAM mode, the aerial effects are enhanced by the way the Sirius lamp is made. It is capable of extraordinary power output (over 300,000 lux at 10mt distance), which the optical unit enhances through a marked hot spot. In SPOT mode, the light is diffused in a more even way which means visual effects can be projected with excellent uniformity.

Its 3° to 36° (1:9) zoom covers the entire range linearly, both in spot mode and in beam mode. This feature makes the Sharpy Plus unique on the market.

The Sharpy Plus has no match. With its wide range of effects and high light output, it beats all the lights in the same category and comes very close to those of higher wattages, but with a much more appealing price tag.

  • Light Source
    330W X8 HRI Sirius Osram arc lamp
  • Light Output
    12000 lm
  • Zoom range
    3°- 36°
  • Effects
    CMY colour mixing; 15 colours on 3 wheels; 2 CTO filters; Rotating Gobo Wheel: 8 interchangeable glass gobos; Static Gobo Wheel: 18 static gobos; Rotating 4-facet prism; Rotating 8-facet prism; Animation Wheel; Linear soft edge frost filter; Dimmer and stop/strobe
Data Sheet DMX Channels Photometrics PDF

Highlights

Specs

Save as pdf and print

LIGHT SOURCE TYPE

  • 330W X8 HRI Sirius Osram Arc Lamp
  • Colour Temperature: 8000K ±300
  • Lamp life expectancy: 1500 hrs
    *It may vary depending on various factors, as type of use and environment

PHOTOMETRIC DATA

  • Zoom range: 3°- 36°
  • 12000 Lumen Output
  • Front lens diameter: 135mm
  • High efficiency optical system

NOISE LEVEL

  • Auto fan mode:49.0 dBA

CONTROL and CONNECTIONS

  • Personalities: Single mode with 31 control channels
  • Control Protocol: DMX, Art-Net, RDM, sACN.
  • DMX and RDM connectors: Locking 5 pin XLR IN/OUT
  • Ethernet port: RJ45 IN
  • Power connector: Power Con True1 IN
  • Built In Web Server

DYNAMIC EFFECTS

  • Colours:
    • Linear CMY colour mixing
    • 5 colors on 3 wheels (2 CTO filters)
  • Gobos:
    • 1 Static gobo wheel with 18 gobos, 6 beam reducers (down to 0.5°)
    • 1 Rotating gobo wheel with 8 HD Indexable and replaceable gobos
    • Ext diam.15.9mm
    • Image diam. 12mm
    • Thickness 1.1mm
  • Frost:
    • Linear soft edge frost filter
  • Rotating Effects
    • Aluminum animation wheel with continuous rotation in both direction at variable speed
    • 4 Facets prism with rotation in both direction at variable speed
    • 8 Facets prism with rotation in both direction at variable speed
  • Movement:
    • Tilt: 270° - 16bit
    • Pan: 540° - 16bit
    • Accuracy: Resolution ± 0,28° (Range 0,56°)
    • Automatic repositioning
    • Fast/Standard speed selectable by Function channel
    • Mechanical Pan/Tilt lock for safe transportation and maintenance
  • Beam:
    • Motorized Zoom and Focus
  • Dimmer/Shutter:
    • High resolution Dimmer - 16 bit
    • High speed Shutter and Strobe

HARDWARE and SOFTWARE

  • Long life self-charging battery
  • Display Graphic LCD backlit b/w Display
  • Firmware upload from another fixture
  • Firmware Upgrade via Web Server
  • Diagnostic
  • DMX monitoring
  • Remote access through RDM
  • CloudIO compatibility

HOUSING

  • Aluminum and steel structure with plastic covers
  • Two side handles for transportation
  • IP20 protection rate

WORKING POSITION

  • Working in any position
  • Hanging system: with fast-lock omega clamps (1/4 turn) on the base
  • Optional safety chain

ELECTRICAL

  • Operating Voltage: 100-240V, 50/60 Hz
  • Power Supply: Electronic auto range with active PFC
  • Max Power consumption: 540VA

THERMAL SPECIFICATION

  • Max ambient temperature 40°C (104°F)
  • Min ambient temperature -10°C (14°F).
  • Max temperature of the external surface 90°C (194°F)
  • Total heat dissipation: 1845 BTU/hr ±10% / 1944 kJ/hr ±10%

SAFETY SPECS

  • Fuse T6.3A – 250V
  • Minimum distance of illuminated objects 8 meters (26’ 3”)
  • Minimum distance from flammable materials 0.2 meters (8”)
  • Thermally protected power supply (overheating and cooling failure)
  • Forced ventilation with axial fans

COMPLIANCE

  • CE marking: In conformity with the European Directives:
  • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
  • 2014/30/EU - Electromagnetic Compatibility (EMC)
  • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
  • 2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
  • UKCA: conforms to UK legislation
  • cETLus Listed / cMETus Listed

PACKAGING

  • Carton box + Polystyrene
  • Carton box + Foam shell
  • Flight case + Foam shell (2 positions)

WEIGHT - SIZE

  • 23.0 Kg (50.7 lbs)
  • 307x375mm (base dimension) – 635mm with vertical head (h)
  • Distance between two fixtures 500mm

ACCESSORIES

  • Omega clamps: 2x183102/805 (included)
  • Power cord: CAB02B/802 (included)
  • Foam shell:  F21312/001 (optional)
  • Flight case: CF1000 (optional)
  • Safety Chain: 105041/003 (optional)
  • Frost assembly 5°: 371081/802 (optional)
  • Linear Prism assembly: 371020/803 (optional)
