Volero Wave


Volero Wave is an incredible LED bar with original and innovative features because it is a system of 8 independent moving bodies. With Volero Wave you will have eight separate heads at your disposal, each independently capable of moving on a 220° tilt and giving rise to three-dimensional and volumetric projections that have never been seen before.

Claypaky has always been known for its research and innovation skills, thanks to which it has often introduced fixtures and solutions that revolutionized the world of Entertainment Lighting.

Today we are pleased to present Volero Wave, an incredible LED bar with original and innovative features, because it is a system of 8 independent moving bodies. Each of these heads contains a brand-new mirror-based optical system combined with 40W RGBW LEDs, which express a higher light intensity than any LED bars currently on the market. The innovative concept behind Volero Wave, as well as the main challenge for the Claypaky R&D team, could move the entire light source on its axis, thus preserving the same intensity of the light flux in any position of the tilt range.

The beams always appear extremely sharp and collimated, parallel to each other thanks to the 2.9° projection angle. The synchronized movement produces an impressive wave of light, all the more overwhelming the more Volero Wave fixtures are seamlessly connected.

Claypaky has designed a system that would allow the Volero Waves to be aligned with each other with extreme precision.  They are easily set up and mounted on the truss to create the “wave effect”. Mounted on the Claypaky Panify, they even add an endless PAN rotation at variable speed, making Volero Wave the most dynamic light effect fixture on the market.

Volero Wave adopts all the most important functions that characterize a product for first-class spectacular effects.  We have the pixel mapping for the control of each parameter for each LED pixel and the exclusive Advanced Layers Management, which allows the operator to use three levels of effects simultaneously.

Volero Wave is a new lighting effect that distinguishes any lighting design. It offers the lighting designer the power to create truly original and three-dimensional light scenes within television and film productions, musicals, live events, touring, and any show where you want to stand out. It is a must-see product.

  • Light Source
    8x40W RGBW Osram LEDs (8600K)
  • Light Output
    292 Lumens (single pixel - integrating sphere)
  • Zoom range
    2.9° (Fixed Aperture)
  • Effects
    RGBW Colour Mixing 16 bit; Linear 16bit CTC 2500 – 8000K; Tilt 220° (each module can move independently); High Resolution Electronic Dimmer – 24-bit; High Speed Electronic Shutter and Strobe
Data Sheet DMX Channels Photometrics PDF



Save as pdf and print


  • 8 Each 40W RGBW LED Engine
  • LED Colour Temperature: 8600K
  • LED Life Expectancy: 50000 Hours L70*
    *It may vary depending on various factors, as type of use and environment


  • Zoom: 2.9° (Fixed Aperture)
  • 292 Lumens (single pixel - integrating sphere)
  • Front lenses (8 Each): 86 x 114mm


  • Standard mode: 41.8 dBA


  • Personalities: 4 Modes: 23/24/29/32 Control Channels
  • Control Protocol: DMX, Art-Net, RDM, sACN
  • DMX and RDM Connectors: Locking 5 pin XLR IN/THRU
  • Ethernet Switch: RJ45 IN/OUT
  • Power Connector: Power Con True1 IN/OUT
  • Built In Web Server


  • Colours:
    • RGBW Colour Mixing 16 bit
    • Linear 16bit CTC 2500 – 8000K
  • Movement:
    • Tilt 220° (each module can move independently)
    • Accuracy ±0.08° (Range 0.16°)
    • Smooth & Fast Speed Selectable by Function Channel
  • Dimmer/Shutter:
    • High Resolution Electronic Dimmer – 24-bit.
    • High Speed Electronic Shutter and Strobe


  • Long Life Self-charging Battery
  • Display Graphic LCD backlit Monochrome Display
  • Firmware Upload from Another Fixture
  • Firmware Upgrade via Web Server or CloudIO
  • Diagnostics
  • DMX Monitoring
  • Remote Access through RDM
  • CloudIO Compatible


  • Aluminum and Steel Structure with Plastic covers
  • IP20 Rated


  • Operates in any Position
  • Hanging System: Supplied with Fast-lock Omega Brackets (1/4 turn)


  • Operating Voltage: 100-240V, 50/60 Hz - In/Out Max 4(2) fixtures @ 200-240Vac (@ 100-120Vac)
  • Max Power Consumption: 400VA
  • Max Power Output: 1600VA (for connecting fixture in daisy-chain)
  • Power Supply: Electronic Auto Ranging with active PFC


  • Operating Temperature 40°C (104°F)
  • Minimum Temperature -10°C (14°F)
  • Maximum Temperature of 60°C (140°F)
  • Total Heat Dissipation: 1366 BTU/hr ±10% / 1440 kJ/hr ±10%


  • Minimum distance of illuminated objects 8 meters (26’ 3”)
  • Minimum distance from flammable materials 0.2 meters (8”)
  • Fuse T10A – 250V
  • Thermally protected power supply (overheating and cooling failure)
  • Forced ventilation with axial fans


  • CE: Conforms to the European Directives
  • UKCA: Conforms to UK Regulations
  • cETLus Listed


  • Carton box + Polystyrene
  • Carton Box + Foam shell
  • Flight Case + Foam Shell (2 position)


  • 20.8 Kg (46 lbs)
  • 1000 x 329 x 182mm


  • Omega Brackets: 2x 415102-801 (included)
  • Power Cord: CAB0K1-802 (included)
  • PowerConTrue1 IP65: CON03O (optional)
  • Foam Shell: F21330-001 (optional)
  • Flight Case (2 pos.): CF1015 (optional)
  • Safety Chain: 105041-003 (optional)
  • Frost Lens Kit 1°: CA30090001A2 (optional)
  • Frost Lens Kit 2°: CA30090001B2 (optional)
  • Frost Lens kit 3.5°: CA30090001C2 (optional)
  • Panify Long Bracket: CA3023000102 (optional)
  • Clamp: C21070 (optional)

Immagine dimensione .png


Technical Documentation


For all other detailed documentation login E-Assist

You can find manuals, datasheets, DMX channel charts, photometrics, CAD symbols, spare parts, firmware files, schematics, technical notes, etc... in the new dedicated Claypaky Customer Care website (restricted access)
