Arolla Spot MP


The Arolla Spot MP is the smallest and lightest moving head fixture among others in its class. While small in stature, it delivers powerful light output with its 470-watt white LED engine (at over 22,000 lumens output) and is full of the features you would expect in a much larger, more expensive luminaire.

The eSWAP technology is a unique feature of this series, that is the interchangeability of the gobo module from the spot version with the framing assembly of the profile model. These modules can be moved from their fixture to the other version. The fixture’s electronics immediately recognize and configure the fixture to operate with the module, so users do not have to change the menu system.

Claypaky known for our industry-leading precision optics and color reproduction has given the Arolla Spot MP fixture an optical system with a 6 to 50-degree zoom range, a CMY color mixing system for deep, rich colors (including an unmatched deep red), a seven-color wheel that includes an 88+ CRI enhancement filter, and linear CTO to hit the color temperatures you need. The unit’s source is a native 6000K that does not produce the metallic white that often limits the fixture’s application and color temperature range. For eye-catching aesthetics, the Arolla Spot MP is fitted with a 120-millimeter diameter front lens giving the unit a unique look when viewed from the front.

Arolla Spot MP features two rotating gobo wheels; each has seven rotating high-definition gobos, for effects. Thanks to our exclusive “Go-Bright” technology, there is no light loss or color shift when gobos are inserted into the beam. The unit also includes a rotating animation wheel and a four-facet rotating prism. For beam control, the Arolla Spot MP offers a mechanical iris, a variable frost filter, a 24-bit digital dimmer with four user-selectable dimming curves that maintain color balance throughout the dimming range, and a fast digital stop-strobe. Being universal voltage, the fixture operates on 100 to 240 volts AC and includes five user-selectable fan speed modes: Auto – Sln – Theatre – RnR – Standard.

The Arolla Spot MP weighs less than 24 kilograms, or 50 pounds, making it one of the lightest moving head spot fixtures available, without giving up the output and features often found in much larger and heavier fixtures.

The Arolla Spot MP fixtures’ versatility allows them to fit comfortably and perform in tours, theatres, or fixed installations.

  • Light Source
    470W white LED engine (6000 K)
  • Light Output
    22,000 lm (in integrating sphere)
  • Zoom range
    6.2°-48.8° linear zoom
  • Effects
    Linear CMY colour mixing; Linear CTO ; 7-color wheel; 2 Rotating gobo wheels; Linear heavy frost 5°; Animation wheel; 4 Facets prism ; Morotized Iris; Motorized Zoom and Focus; High resolution electronic Dimmer; High speed electronic Shutter and Strobe
Data Sheet DMX Channels Photometrics PDF



Save as pdf and print


  • 470W White LED Engine
  • CRI: 70+ with selectable filter for typical CRI value up to 90
  • Colour Temperature: 6000K
  • LED life expectancy: 40000Hrs L70*
    *It may vary depending on various factors, as type of use and environment


  • Zoom range: 6.2°- 48.8°
  • 22054 Lumen Output (Integrating Sphere)
  • Front lens diameter: 120 mm
  • High efficiency optical system


  • Theatre fan mode: 40.6 dBA
  • SLN fan mode: 40.6 dBA
  • Standard fan mode: 46.8 dBA
  • Auto fan mode: 48.4 dBA
  • RNR fan mode: 48.7 dBA


  • Personalities: Single mode with 29 control channels
  • Control Protocol: DMX, Art-Net, RDM, sACN
  • DMX and RDM connectors: Locking 5 pin XLR IN/OUT
  • Ethernet port: RJ45 IN
  • Power connector: PowerCon True 1
  • Built In Web Server


  • Colours:
    • Linear CMY colour mixing
    • Linear CTO
    • Fixed color wheel with 7 dichroic colors including High CRI filter
  • Gobos:
    • 2 Rotating gobo wheel with 7 HD Indexable and replaceable gobos
    • Ext diam.22.9mm
    • Image diam. 17mm
    • Thickness 1.1mm
    • The Gobo module is interchangeable with the optional Framing version without any setting
  • Frost:
    • Linear heavy frost 5° for wash effect
  • Rotating Effects
    • Aluminum animation wheel with continuous rotation in both direction at variable speed
    • 4 Facets prism with rotation in both direction at variable speed
  • Iris:
    • Motorized with variable pulse and random effects
  • Movement:
    • Tilt: 270° - 16bit
    • Pan: 540° - 16bit
    • Accuracy: Resolution ± 0.17° (Range 0.54°)
    • Automatic repositioning
    • Fast/Standard speed selectable by Function channel
    • Mechanical Pan/Tilt lock for safe transportation and maintenance
  • Beam:
    • Motorized Zoom and Focus
  • Dimmer/Shutter:
    - High resolution electronic Dimmer - 24 bit
    - High speed electronic Shutter and Strobe



  • Long life self-charging battery
  • Display Graphic LCD backlit b/w Display
  • Firmware upload from another fixture
  • Firmware Upgrade via Web Server
  • Diagnostic
  • DMX monitoring
  • Remote access through RDM
  • CloudIO compatibility


  • Aluminum and steel structure with plastic covers
  • Two side handles for transportation
  • IP20 protection rate


  • Working in any position
  • Hanging system: with fast-lock omega clamps (1/4 turn) on the base pn 183102/805
  • Optional safety chain


  • Operating Voltage: 100-240V, 50/60 Hz
  • Power Supply: Electronic auto range with active PFC
  • Max Power consumption: 740VA


  • Max ambient temperature 45°C (113°F)
  • Min ambient temperature -20°C (-4°F)
  • Max temperature of the external surface 90°C (194°F)
  • Total heat dissipation: 2527 BTU/hr ±10% / 2664 kJ/hr ±10%


  • Minimum distance of illuminated objects 2.5 meters (8’ 2”)
  • Minimum distance from flammable materials 0.2 meters (8”)
  • Fuse T10A – 250V
  • Thermally protected power supply (overheating and cooling failure)
  • Forced ventilation with axial fans


  • In conformity with the European Directives:
  • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
  • 2014/30/EU - Electromagnetic Compatibility (EMC)
  • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
  • 2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
  • cMETus Listed


  • Carton box + Polystyrene
  • Carton box + Foam shell
  • Flight case + Foam shell (4 positions)


  • 23.7 Kg (52.2 lbs)
  • 250x360mm (base dimension) – 593mm with vertical head (h)
  • Distance between two fixtures 480mm


  • Omega clamps: 2 x 183102/805 (included)
  • Power cord: CAB02B/802 (included)
  • Foam shell: F21324/001 (optional)
  • Flight case 4 positions: CF1008 (optional)
  • Safety Chain: 105041/003 (optional)
  • Arolla Profile MP framing module conversion kit: CA3008C00100 (optional)
