Axcor Spot 300


The new Axcor 300 family of moving LED fixtures brings Claypaky’s no-compromise quality and performance to the broad mid-market. The quality of their effects, their construction, and their high light output derive from the high-end products Claypaky specializes in.

The Axcor Spot 300 has 17 gobos on 2 wheels, including 7 high quality dichroic  rotating  gobos.  Weighing just 20 Kg and measuring a little over 500 mm, this unit incorporates features that are not often found in models of this size, like a rotating prism, a motorised iris, a soft edge filter, a 16-bit dimmer, and a 8-40° zoom.

It boasts cutting- edge electronic and software technology, with all the features that enable optimal fixture management and maintenance over time.With a price-point, physical size and power consumption that disguise its strength and creative potential, the Axcor Spot 300 enables a new world of expression in touring, events, TV, theatre and installed lighting markets.

  • Light Source
    180W White LED engine
  • Zoom range
    8°-40° linear zoom
  • Effects
    CMY System; 7 color wheel; One wheel with 7 rotating gobos; One wheel with 10 fixed gobos; Rotating 4-facet prism; Mechanical Iris; Frost filter; 16-bit Electronic Dimmer with 4 curves; Electronic strobe@24 f/sec
Data Sheet DMX Channels Photometrics PDF


Save as pdf and print


  • 180W White LED engine
  • Colour Temperature: 7000K
  • Lamp life expectancy: 20000hrs
    *It may vary depending on various factors, as type of use and environment


  • 8°-40° linear zoom
  • Motorised focus lens
  • High efficiency optical system


  • DMX 512 control channels 23
  • Control signal USITT DMX 512
  • Protocols RDM, Artnet, sACN, WebServer
  • Display Graphic LCD backlit b/w Display
  • Display battery self-charging buffer battery
  • 16-bit Electronic Dimmer with 4 curves
  • Electronic strobe@24 f/sec
  • Pan/Tilt Resolution 16 bit
  • Dimmer Resolution 16 bit
  • DMX signal connection 5 pole XLR input and output


  • CMY System
  • One color wheel with 7 colors (including 1 CTO filter)
  • One wheel with 7 rotating gobos
  • One wheel with 10 fixed gobos
  • Rotating 4-facet prism
  • Mechanical Iris
  • Frost filter
  • Movement: - Tilt: 270° - 16bit - Pan: 540° - 16bit
  • Automatic repositioning
  • Mechanical Pan/Tilt lock for safe transportation and maintenance
  • Beam: Motorized Zoom and Focus
  • Dimmer/Shutter: 16-bit Electronic Dimmer with 4 curves
  • Shutter and Strobe effect


  • Long life self-charging battery
  • Display Graphic LCD backlit b/w Display
  • Firmware upload from another fixture
  • Firmware Upgrade via Web Server
  • Diagnostic
  • Electronic monitoring with status error
  • Remote access through RDM
  • CloudIO compatibility
  • Long life self-charging buffer battery
  • Function reset from the lighting desk
  • “AUTOTEST” function from menu
  • Cooling system monitoring
  • Protocols/Functions: RDM, Artnet, sACN, Web Server


  • Aluminum and steel structure with plastic covers
  • Two side handles for transportation
  • IP20 protection rate


  • Working in any position
  • Hanging system: with fast-lock omega clamps (1/4 turn) on the base
  • Optional safety chain


  • Operating Voltage: 100-240V, 50/60 Hz
  • Power Supply: Electronic auto range with active PFC
  • Max Power consumption: 340VA


  • Max ambient temperature 40°C (104°F)
  • Max temperature of the external surface 90°C (194°F)


  • Minimum distance of illuminated objects 3 meters (9’ 10”)
  • Minimum distance from flammable materials 0.2 meters (8”)
  • Thermally protected power supply (overheating and cooling failure)
  • Forced ventilation with axial fans


  • CE marking: In conformity with the European Directives:
  • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD)
  • 2014/30/EU - Electromagnetic Compatibility (EMC)
  • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS)
  • 2009/125/EC - EcoDesign requirements for Energy-related Products (ErP)
  • UKCA: conforms to UK legislation
  • cMETus Listed


  • Carton box + Polystyrene
  • Carton box + Foam shell
  • Flight case + Foam shell (2 positions)


  • 20.2 Kg (44.53 lbs)


  • Omega clamps: 2x183102/805 (included)
  • Power cord: CAB02B/802 (included)
  • Foam shell: F21304/001 (optional)
  • Flight case 2 positions: F21307 (optional)
  • Safety Chain: 105041/003 (optional)

Dimensioni prodotto


Technical Documentation


For all other detailed documentation login E-Assist

You can find manuals, datasheets, DMX channel charts, photometrics, CAD symbols, spare parts, firmware files, schematics, technical notes, etc... in the new dedicated Claypaky Customer Care website (restricted access)

Sign In

Gobos and filters

Download the Axcor Spot 300 Gobos and Filters

Catalogues and Brochures

Axcor range

Download PDF
